transparent led display manufacturers
Product Attributes :
Brand Name: HOMEWELL
Screen Material: Tempered Glass
Pixel Pitch:5.5*11/11*11/11*22/22*22
LED chip:SMD1812
Screen Size:support customization
Specification:Digital Poster, Video Wall
Brightness:5000nits
Life span:100000 Hrs
Waterproof:IP65 Level
Warranty:1 Years
Product Description
Call screen series
It is mainly used in the public office of government administration hall, hospital, bank and high-speed railway station
The hall of affairs. Because the product itself is highly transparent, beautiful, easy to use and other characteristics,
Well received by the majority of customers need and use. unlimited potential.
| SPECIFICATION | ||||
| Product | LED Transparent Chip Display | |||
| Type | P6 | |||
| Product Model | P6 Indoor Full Color Display | |||
| ( 1)Pixel point parameter |
To achieve the best white balance effect in color matching,the color-matching ratio ofvarious color brightness is required to be R:G:B/3:6:1. |
|||
| 1 | LED lamp type | 1 red,1 green,1 blue (chip) | ||
| 2 | Dot pitch | Horizontal 6.25mm,Vertical 6mm | ||
| 3 | Pixel composition | 1R1G1B | ||
| (2)Module technical parameters |
||||
| 1 | Module resolution (width x height) | 160 pixels ×40 pixels | ||
| 3 | Flatness between modules | ≤0.1mm | ||
| 4 | Module size (width ×height x thickness) | 1000mm(customizable)*240mm*2mm | ||
| 5 | Module weight | 0.3Kg/Module | ||
| 6 | Installation method | Directly adhered to glass /Can be clamped inside tempered glass /Inner arc installation /Supports size cutting and bending |
||
| (3)Screen technical parameters | ||||
| 1 | Point density | 26560 point/m² | ||
| 2 | Brightness | 1000cd~2000cd/m²Adjustable | Brightness | 1000cd~2000cd/m²Adjustable |
| 3 | Horizontal /Verticalviewing angle | 140°/140° | Horizontal /Verticalviewing angle | 140°/140° |
| 4 | Flatness | ≥98% | Flatness | ≥98% |
| 5 | Chromaticity uniformity | ±0.003 Cx,Cy Within | Chromaticity uniformity | ±0.003 Cx,Cy Within |
| 6 | Maximum contrast ratio | 4000:1 | Maximum contrast ratio | 4000:1 |
| 7 | Protection level | IP43 | Protection level | IP43 |
| (4)System controlparameters | ||||
| 1 | Signal color processing bits | Each of red,green,andblue ≥16bit | Signal color processing bits | Each of red,green,andblue ≥16bit |
| 2 | Driving mode | Constant current dynamic | Driving mode | Constant current dynamic |
| 3 | Frame change frequency | 60 frames /second.Highbrush supports 3D:120 frames /second |
Frame change frequency | 60 frames /second.Highbrush supports 3D:120 frames /second |
| 4 | Refresh rate | ≥3840Hz | Refresh rate | ≥3840Hz |
| 6 | Screen color temperature | 2000K~9500K Adjustable | Screen color temperature | 2000K~9500K Adjustable |
| 7 | Brightness adjustment | Manual/Automatic /Programmed | Brightness adjustment | Manual/Automatic /Programmed |
| 8 | Pixel correction | Equipped with point-by-point correction of brightnessand chromaticity |
Pixel correction | Equipped with point-by-point correction of brightnessand chromaticity |
| 9 | Control method | Synchronous and asynchronous control (Nova / Colorlight) |
Control method | Synchronous and asynchronous control (Nova / Colorlight) |
| 10 | Control distance | Cat 5e twisted-pair network cable.Fiber optic transmission is used when exceeding 100 meters |
Control distance | Cat 5e twisted-pair network cable.Fiber optic transmission is used when exceeding 100 meters |
| 11 | Software interface | Windows | Software interface | Windows |
| 12 | Signal input | HDMI、DVI | Signal input | HDMI、DVI |
| (5)Screenoperation parameters | ||||
| 1 | Operating voltage | AC:110V~240V、50~60Hz | Operating voltage | AC:110V~240V、50~60Hz |
| 2 | Peak power | ≤180W/m² | Peak power | ≤180W/m² |
| 3 | Average power | 50W/m²~60W/m² | Average power | 50W/m²~60W/m² |
| 4 | Continuous working time | ≥7 x 24hrs,supports continuous and uninterrupted display |
Continuous working time | ≥7 x 24hrs,supports continuous and uninterrupted display |
| 5 | Average trouble-free working time | ≥10000hrs | Average trouble-free working time | ≥10000hrs |
| 6 | LED chip life | 100,000 hours | LED chip life | 100,000 hours |
| 7 | Discrete out-of-control points | ≤0.001,0 at factory | Discrete out-of-control points | ≤0.001,0 at factory |
| 8 | Continuous out-of-controlpoints | 0 | Continuous out-of-controlpoints | 0 |
| 9 | Blind spot rate | ≤0.001,0 at factory | Blind spot rate | ≤0.001,0 at factory |
| 10 | Screentemperature rise(during operation) | s3 degree | Screentemperature rise(during operation) | s3 degree |
| 11 | Operating environment temperature | -10℃~60℃ | Operating environment temperature | -10℃~60℃ |
| 12 | Operating environment humidity | 10%-90%RH,no condensation | Operating environment humidity | 10%-90%RH,no condensation |
